Neousys Technology

Серия Nuvo-10109GC (новинка!)

Name: Серия Nuvo-10109GC (новинка!)
Brand: Neousys Technology
SKU: NUVO-10109GC
Availability: PreOrder

Цена по запросу

Для B2B-заказов цена, срок и состав поставки фиксируются в счёте. Каталог не является публичной офертой. НДС не облагается (продавец применяет УСН).

Под заказ

Запросить цену

На складе0 шт.

Производитель: Neousys Technology
Модель: Nuvo-10109GC Series (New!)
Артикул: NUVO-10109GC
Категория: Edge-компьютеры и серверы
Key Features: Supports single 600W GPU with Gen4 x16 signal and dedicated GPU-locking bracket; Intel® 14th/ 13th/ 12th-Gen Core™ 35W/ 65W LGA1700 CPU; Up to 128GB ECC/ non-ECC DDR5 4800 with Intel R680E chipset (2x SODIMM); Three x8 PCIe slots with Gen3 x4 signal for add-on cards; 6x USB 3.2, 2x 2.5GbE, 1x GbE, and 1x optional 10GbE; Two front-accessible storage options: 1x 2.5" SATA tray and 1x optional NVMe tray; 9V to 32V wide-range DC input with ignition power control; Rugged, -25°C to 60°C operation

Описание

Nuvo-10109GC — это значительное усовершенствование платформы периферийного искусственного интеллекта от Neousys, разработанное для новейшего графического процессора NVIDIA Blackwell мощностью 600 Вт, обеспечивающее до 4000 AI TOPS для логического вывода FP4 LLM и генеративного искусственного интеллекта или 125 терафлопс для автономного вождения и приложений компьютерного зрения на основе искусственного интеллекта.

Гайд: как выбрать Вычислители — критерии, интерфейсы и типичные ошибки

Характеристики

Key Features	Supports single 600W GPU with Gen4 x16 signal and dedicated GPU-locking bracket; Intel® 14th/ 13th/ 12th-Gen Core™ 35W/ 65W LGA1700 CPU; Up to 128GB ECC/ non-ECC DDR5 4800 with Intel R680E chipset (2x SODIMM); Three x8 PCIe slots with Gen3 x4 signal for add-on cards; 6x USB 3.2, 2x 2.5GbE, 1x GbE, and 1x optional 10GbE; Two front-accessible storage options: 1x 2.5" SATA tray and 1x optional NVMe tray; 9V to 32V wide-range DC input with ignition power control; Rugged, -25°C to 60°C operation
Processor	Supporting Intel® 14th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP) - Intel® Core™ i9-14900/ i9-14900T - Intel® Core™ i7-14700/ i7-14700T - Intel® Core™ i5-14500/ i5-14400/ i5-14500T - Intel® Core™ i3-14100/ i3-14100T
Chipset	Intel® R680E Platform Controller Hub
Graphics	Integrated Intel® UHD Graphics 770 (32EU)/ 730 (24EU)
Memory	Up to 128GB ECC/ non-ECC DDR5 4800 SDRAM (up to 2x 64GB SODIMM modules)
AMT	Supports Intel vPro/ AMT 16.0
TPM	Supports dTPM 2.0
Ethernet	2x 2.5G Ethernet by I226-IT and 1x Gigabit Ethernet by I219-LM
10G Ethernet (optional)	1x 10GBASE-T port by Marvell AQC113CS, supporting NBASE-T(5G/2.5G) and 1000BASE-T (Optional)
USB	6x USB 3.2 Gen2x1 (10 Gbps) ports 1x USB 2.0 ports (internal for dongle use)
Video Port (Integrated Graphics)	1x VGA connector, supporting 1920 x 1200 resolution, 1x DisplayPort connector, supporting 4096 x 2304 resolution
Serial Port	2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2)
Audio	1x 3.5 mm jack for mic-in and speaker-out
SATA HDD	1x front-accessible, hot-swappable HDD tray for 2.5" HDD/SSD installation
M.2	1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD 1x front-accessible M.2 2280 M key tray (PCIe Gen4 x4) for NVMe SSD (Optional) 1x M.2 2242/3052 B key socket with internal SIM sockets
PCI Express	1x PCIe x16 slot @Gen4, 16-lanes (70 mm slot width) GPU locking bracket for RTX Pro 6000, and selected GPU Cards 3x PCIe x8 slots @Gen3, 4-lanes
mini-PCIe	2x full-size mini PCI Express sockets with internal SIM sockets
DC Input	3-pin + 4-pin pluggable terminal block for 9V to 32V DC input with ignition control
Dimension	224 mm (W) x 400 mm (D) x 196 mm (H) (without damping bracket)
Weight	7.1 kg
Mounting	Wall-mount with damping brackets
Operating Temperature	With 35W CPU and NVIDIA 600W GPU: -25°C to 60°C With 65W CPU and NVIDIA 600W GPU: -25°C to 60°C (with optional fan kit) -25°C to 50°C(without optional fan kit)
Storage Temperature	-40°C ~ 85°C
Humidity	10%~90% , non-condensing
Vibration	MIL-STD-810H, Method 514.8, Category 4 (with damping bracket)
Shock	MIL-STD-810H, Method 516.8, Procedure I
EMC	CE/FCC Class A, according to EN 55032 & EN 55035
PCIe-PoE354at 4-port gigabit 802.3at PoE+ card	PCIe-PoE312M 4-port gigabit 802.3at PoE+ Card with M12 x-coded Connectors
Dimensions	224 mm (W) x 400 mm (D) x 196 mm (H) (without damping bracket)
Chassis Construction	-
PoE	-
Video Port	1x VGA connector, supporting 1920 x 1200 resolution, 1x DisplayPort connector, supporting 4096 x 2304 resolution
mSATA/eSATA	1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD 1x front-accessible M.2 2280 M key tray (PCIe Gen4 x4) for NVMe SSD (Optional)
Mini PCI-E	2x full-size mini PCI Express sockets with internal SIM sockets
PCI/PCI Express	1x PCIe x16 slot @Gen4, 16-lanes (70 mm slot width) GPU locking bracket for RTX Pro 6000, and selected GPU Cards 3x PCIe x8 slots @Gen3, 4-lanes
Certification	CE/FCC Class A, according to EN 55032 & EN 55035
New Date	2026-01-02
Product Line	Industrial Computers

О товаре

Развернуть текст

5" SATA tray and 1x optional NVMe tray; 9V to 32V wide-range DC input with ignition power control; Rugged, -25°C to 60°C operation; Processor: Supporting Intel® 14th-Gen Core™ CPU (LGA1700 socket, 65W/ 35W TDP) - Intel® Core™ i9-14900/ i9-14900T - Intel® Core™ i7-14700/ i7-14700T - Intel® Core™ i5-14500/ i5-14400/ i5-14500T - Intel® Core™ i3-14100/ i3-14100T; Chipset: Intel® R680E Platform Controller Hub; Graphics: Integrated Intel® UHD Graphics 770 (32EU)/ 730 (24EU); Memory: Up to 128GB ECC/ non-ECC DDR5 4800 SDRAM (up to 2x 64GB SODIMM modules). Цена по запросу, под заказ. Доставка по России, отгрузка для юридических лиц, КП по запросу.
